APPLICATIONS

Icon cycle-paths

Cycle paths

Icon Footpaths

Footpaths

Icon Residential streets

Residential streets

Icon Residence areas

Residence areas

APPLICATIONS

APPLICATIONS

• Mounting: U-bracket or suspended
• Recommended heights: 4,5 to 7 m
• Urban streets, pedestrians, cycle paths, squares

DESCRIPTION

  • Injected die cast aluminium corps, dome, bracket
  • Polycarbonate conical clear bowl (PTC)
    (only with bracket)
  • Polycarbonate short clear bowl (PCC)
    (only suspended without bracket)
  • Polyester powder coating, any colour available
  • IP 66
  • IK 08
  • Class I or II
  • Perle module (ORALED 1 type) with ORALENS lenses, module painted 2150 or 2900 sanded grey
  • Colour temperature: 4000 K and 3000 K

CITIZEN REFERENCE POINTS

• Materials used:
Aluminium 87%, Steel 5%, Other 5%, Plastic 3%
• Complies with the RoHS directive
• High recyclability rat

WATERPROOFING

• IP 66 waterproofing in accordance with the standard EN 60 529 • Extruded silicone gasket
• Breathing system with activated carbon filter

MECHANICAL INTERFACES

  • Top-mounted U-bracket: fastening Ø 42 mm, L 70 mm
  • Suspended: swivel joint and Ø 34pdg (G1’’) thread for female boss - Length 35 mm
  • Options: trims Ø 76 and Ø 89 mm and Catelux fixation

DIMENSIONS

Ø: Perle: 415 mm / Perle U-bracket: 490 mm
Height: Perle: 310 mm / Perle U-bracket: 890 mm
Weight: Perle: 8,8 Kg / Perle U-bracket: 17,5 kg / Perle Post top: 18,5 kg
Scx: Perle: 0,07 m2 / Perle Lyre: 0,11 m2

CONNECTIVITY

• 0-10V
• DALI
• SR+Zhaga (D4I)
• Bluetooth
