PALEO

design by Eclatec

PALEO is the successful combination of principles and reality.

Its form, finalised and modern, also speaks of functionality. In this regard, PALEO has many assets, its adaptability, the ease of opening and its large-sized equipment compartment.

Its sober silhouette, translates an efficiency of good quality, ideally suited for major roads such as city approaches.

APPLICATIONS

Icon cycle-paths

Cycle paths

Icon Footpaths

Footpaths

Icon Residential streets

Residential streets

Icon Residence areas

Residence areas

APPLICATIONS

APPLICATIONS

• Mounting: top and side entry
• Recommended heights: 4 to 10 m
• Urban routes, pedestrian walkways, cycle paths, squares, parks and pedestrian areas

DESCRIPTION

• Injection die-cast aluminium body
• Luminaire opens without tools
• Control gear integrated on a removable tray, disconnectable without tools • Polyester powder coating, any colour available
• IP 66
• IK 07
• Class I or II
• TABLED 2 module with a TABLENS mono lens in PMMA, IK 07
• Colour temperature: 4000 K and 3000 K

RETROFIT

• The TABLED 2 module can be used to equip Paleo luminaires that were initially equipped with discharge lamps.

CITIZEN REFERENCE POINTS

• Materials used: Aluminium 90%, Other 7%, Plastic 2%, Steel 1%
• Complies with the RoHS directive
• High recyclability rate

WATERPROOFING

• IP 66 waterproofing in accordance with the standard EN 60 529
• Extruded pneumatic silicone gasket
• Cable gland with anchoring device
• Breathing system with activated carbon filter

MECHANICAL INTERFACES

  • Luminaire post top mounted on pole Ø 60/62 mm
    For pole Ø 76 mm top, optional spigot B
    Tilts 0°, 5°, 10° and 15°
  • Luminaire lateral mounted on bracket Ø 42, 49 and 60 mm
    Tilts 0°, -5°, -10° and -15°

DIMENSIONS

Length: 754mm Width: 334mm Height: 248mm Weight: 12,7kg Scx: 0,07m2

CONNECTIVITY

• 0-10V
• DALI
• SR+Zhaga (D4I)
• Bluetooth
