KEO LED

Lighting
← →

KEO is a decorative urban LED luminaire, primarily designed for pedestrian public spaces.

It’s design makes the best use of LED technology; in effect, this luminaire offers innovative visual comfort by way of a unique gentle light diffusing design.

To this end, the designer has created an original underside, in relief, which reduces glare at night without altering the lighting level. Available as an option, this wide, retro-lit, underside seduces with its subtle presence.

By day, a mirror effect dims the surface as you move away from the object and favours its integration into the environment, as does the simple and refined general design of KEO, offering a thin and equally discrete silhouette.

APPLICATIONS

Footpaths

Residential streets

Residence areas

APPLICATIONS

Mounting: Post-top
Urban routes, pedestrian walkways, cycle paths, squares, parks and pedestrian areas.
Recommended heights: 4 to 5 m

DESCRIPTION

Injection die-cast aluminium body
Two-material polycarbonate opal and clear bowl, with Led backlight as an option: white or other colours on request
Polyester powder coating, any colour available
IP 66
IK 10
KEO source with UNILENS lenses
Colour temperature: 4000 K and 3000 K
Class I or II
Luminaire pre-wired in the factory (6 m)

CITIZEN REFERENCE POINTS

• Materials used:
- Aluminium 70%, Plastic 20%, Steel 8%, Other 2%
• Complies with the RoHS directive
• High recyclability rate

WATERPROOFING

• IP 66 waterproofing in accordance with the standard EN 60 529
• Entry sleeve with membrane seal
• Extruded silicone gasket
• Breathing system with activated carbon filter
